| Drill depth(m) | 150 |
| Borehole diameter(mm) | Ф125~250 |
| Drill pipe specifications(mm) | Ф73~Ф114*3000 |
| Power head output speed(convention)(rpm) | 25 /50, 51/102 |
| (accelerate)(rpm) | 41 /82, 83/166 |
| Power head high output torque(Nm) | 8500 |
| Power head stroke(mm) | 2800(customizable 3800mm) |
| Powerhead with high lifting force(kN) | 65 |
| The power head provides high thrust(kN) | 50 |
| Mast sliding stroke(mm) | 800 |
| Upward turning angle(°) | -30~90 |
| Gradeability(°) | 20° |
| Power (either Electric or Firewood) | |
| Firewood engine power(kW) | 125 |
| Electricity Motivation Power(kW) | 55+22 |
| External dimensions of drilling rig (transportation status)(mm) | 約6100×2000×2300 |
| Drill weight(kg) | 約8000 |
| Optional accessories | a) 1.1 ton tool winch (and overhead crane); b) Mud pump< br/> c) Wet dust removal device; d) Drill pipe lifting device; |
